We will guide you through the EST or Channel System. If you have a 4x4 disc system, here is a guide just for you.
What Are EST Bindings?
EST (Extra Sensory Technology) bindings are designed to provide a more natural flex and feel underfoot. Unlike traditional bindings, they use a channel system that allows for infinite stance options. If you have just purchased a Burton board, you will have an EST set up.
Gather Your Tools and Materials
Before you start, make sure you have the following items:
- Snowboard with the Channel system
- EST bindings
- A Phillips head screwdriver
- EST Hardware - the screws will be in the box with your bindings, and the plugs will come with your snowboard
- Tape measure or ruler (optional, but helpful for precise measurements)
Determine Your Stance
Your stance refers to the direction, position and angle of your feet on the snowboard. Your stance might change as you spend more time on your snowboard, and play around with different angles and widths.
Things to consider:
- Regular or Goofy: The first step is to determine which foot will be your lead foot. Regular riders lead with their left foot, whilst goofy riders lead with their right. If you are unsure of your riding stance, a tip is to slide along a smooth floor surface in socks; the foot you naturally lead with should be your lead foot.
- Stance Width: Your stance width is the distance between the centre of each binding. Most snowboards will have a reference mark to show the suggested width. Start here and adjust the width to your personal preference. If unsure, shoulder width is always a safe place to start.
- Stance Angles: The angle at which your bindings are set affects your riding style. A common setup is +12 degrees on the front binding and -12 degrees on the back binding. Experiment with different angles to find what feels best for you. However, someone looking for a more all-mountain or carving stance may play around with a straighter back foot, which would look like +12 and -9 or -6. Experiment with different angles to find what feels best for you.
Setting up the hardware
- Lay your snowboard on a flat surface and remove the rubber stoppers. Using a screwdriver can make this easier.
- Place the t-bolt in the gap, then slide it up the channel and repeat with the second t-bolt plug. Replace the rubber stopper to secure the plugs in the channel. Repeat this process for the second channel.
- Spread the plugs about the width of the binding and place the plastic ridge under the binding, in the channel. This ridge locking into the channel will then indicate the binding angle, the width, and the centre positioning of the binding.
- Place one of the winged washers and screws over the plug and lightly screw them down.
- With the screw slightly loose, you can play with your width, angles and positioning on the board.
- Once you are happy with your stance you can screw the bindings down tightly to secure.
Adjust the Straps and Highbacks
With the bindings securely mounted to the board, you can now adjust the straps and highbacks for optimal comfort and performance. Place your boots in your bindings and check everything fits correctly. Check that there is no toe or heel drag and your boot centre.
- Straps: Adjust the toe and heel straps to fit snugly over your boots without causing discomfort. The ankle strap should hold your boot firmly, while the toe strap should prevent your foot from sliding forward. The shape of the binding straps should match the natural shape of the boot and not cause any pressure points when done up. The straps should not have to be maxed out to secure your boot down. If this is the case, then the strap needs to be adjusted
- Highbacks: The highback is the vertical part of the binding that supports your calf. Adjust the forward lean of the highback according to your riding style. More forward lean provides better control for aggressive riding, while less forward lean offers a more relaxed stance. Forward lean might be something you play around with on the mountain. Try a couple of runs with no forward lean and slowly adjust until you find the perfect level for you and your riding style.
Forward lean is the amount of forward angle on a binding highback, or the angle at which your calves are pushed forward. The further forward your calves, the more you will bend at the knees and be able to add power and control to your turns. Adding forward lean will put you in a more athletic position, making it easier to hold a toeside or heelside edge. Remember that forward lean is not a ‘more the better’ addition to your setup. Start on 1 and feel it out.
Fine-Tuning and Testing
Take your snowboard for a test run to see how it feels. Pay attention to any discomfort or issues with control. Adjust the stance width, angles, and strap tightness as needed. Remember to take note of any toe or heel drag that might be occurring. It's important to find a setup that feels comfortable and responsive.
Setting up your snowboard bindings correctly is essential for a safe and enjoyable ride. By following these steps, you can ensure that your bindings are properly aligned, securely attached, and customised to your preferences. Everyone’s ideal setup is different, so don’t be afraid to experiment until you find what works best for you. Happy shredding!
Feel free to ask if you have any questions or need further assistance with your snowboard setup!
